Table 7. Service Processor Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
4B2E 301F Processor system and scan control routines
detected 128 MB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2E 303A Processor system and scan control routines
detected 1 GB DIMM fault
Memory DIMM
Locations: U1.1-P1-M1.n
U1.1-P1-M2.n
4B2E 515B Processor system and scan control routines
detected 1100W ac power supply fault
1100W ac power supply
Locations: U1.1-V1
U1.1-V2
4B2E 51AC Processor system and scan control routines
detected 595W ac power supply fault
595W ac power supply
Locations: U0.1-V1
U0.1-V2
4B2E 51AD Processor system and scan control routines
detected 595W dc power supply fault
595W dc power supply
Locations: U0.1-V1
U0.1-V2
4B2E 51AE Processor system and scan control routines
detected 1100W dc power supply fault
1100W dc power supply
Locations: U1.1-V1
U1.1-V2
4B2F 245B Processor system and error code detected
2W 4M processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 245C Processor system and error code detected
2W 2M processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 245D Processor system and error code detected
4W 4M processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 248B Processor system and error code detected
primary I/O drawer operator panel fault
Operator Panel
Location: U0.1-L1
4B2F 24A5 Processor system and error code detected
2W 500 MHz processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 24A6 Processor system and error code detected
4W 500 MHz processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 25AB Processor system and error code detected
400 MHz clock fault
400 MHz clock
Location: U1.1-P1.1.1
4B2F 25AD Processor system and error code detected
540 MHz clock fault
540 MHz clock
Location: U1.1-P1.1.1
4B2F 25B1 Processor system and error code detected
750 MHz clock fault
750 MHz clock
Location: U1.1-P1.1.1
4B2F 25B3 Processor system and error code detected
4W 750 MHz processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 25B4 Processor system and error code detected
2W 750 MHz processor fault
Go to “MAP 1540: Minimum Configuration”
on page 110.
4B2F 25DA Processor system and error code detected
500 MHz clock fault
500 MHz clock
Location: U1.1-P1.1.1
4B2F 267D Processor system and error code detected an
8W, 750 MHz regulator fault
8W regulator card
Location: U1.1-P1-V1
4B2F 2687 Processor system and error code detected
remote I/O bus adapter fault
Remote I/O bus adapter
Location: U1.1-P1.1
334 Service Guide
