FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
Memory DIMMs 1 - 32 on
Riser Card 1
U1.1-P1-M1.1
to
U1.1-P1-M1.32
Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad A Odd on
Riser Card 1
U1.1-P1-M1.1x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Octal A on Riser
Card 1
U1.1-P1-M1.1 x8 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
All Memory DIMMs on
Riser Card 1
U1.1-P1-M1.1 x32 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad A Even on
Riser Card 1
U1.1-P1-M1.2 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad B Odd on
Riser Card 1
U1.1-P1-M1.3 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Octal B on Riser
Card 1
U1.1-P1-M1.3 x8 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad B Even on
Riser Card 1
U1.1-P1-M1.4 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad C Odd on
Riser Card 1
U1.1-P1-M1.5 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Octal C on Riser
Card 1
U1.1-P1-M1.5 x8 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
32 Service Guide
