FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
Memory Quad C Even on
Riser Card 1
U1.1-P1-M1.6 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad D Odd on
Riser Card 1
U1.1-P1-M1.7 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Octal D on Riser
Card 1
U1.1-P1-M1.7 x8 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad D Even on
Riser Card 1
U1.1-P1-M1.8 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Riser Card 2 U1.1-P1-M2 00-00 CEC Connector M5
Memory DIMMs 1 - 32 on
riser card 2
U1.1-P1-M2.1
to
U1.1-P1-M2.32
00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad A Odd on
Riser Card 2
U1.1-P1-M2.1 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Octal A on Riser
Card 2
U1.1-P1-M2.1 x8 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
All Memory DIMMs on
Riser Card 2
U1.1-P1-M2.1 x32 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad A Even on
Riser Card 2
U1.1-P1-M2.2 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Memory Quad B Odd on
Riser Card 2
U1.1-P1-M2.3 x4 00-00 Refer to “Memory
Riser Card and
Memory DIMM
Locations” on page
19.
Chapter 1. Reference Information 33
