FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
4W Card 1, Processor 2 U1.1-P1-C1 00-01 Connector M03 in
CEC Drawer
4W Card 1, Processor 3 U1.1-P1-C1 00-02 Connector M03 in
CEC Drawer
4W Card 1, Processor 4 U1.1-P1-C1 00-03 Connector M03 in
CEC Drawer
4W Card 1, Cache U1.1-P1-C1 Connector M03 in
CEC Drawer
Processor Card 2 U1.1-P1-C2 Connector M04 in
CEC Drawer
2W Card 2, Processor 1 U1.1-P1-C2 00-02 Connector M04 in
CEC Drawer
2W Card 2, Processor 2 U1.1-P1-C2 00-03 Connector M04 in
CEC Drawer
2W Card 2, Cache U1.1-P1-C2 Connector M04 in
CEC Drawer
4W Card 2, Processor 1 U1.1-P1-C2 00-04 Connector M04 in
CEC Drawer
4W Card 2, Processor 2 U1.1-P1-C2 00-05 Connector M04 in
CEC Drawer
4W Card 2, Processor 3 U1.1-P1-C2 00-06 Connector M04 in
CEC Drawer
4W Card 2, Processor 4 U1.1-P1-C2 00-07 Connector M04 in
CEC Drawer
4W Card 2 Cache U1.1-P1-C2 Connector M04 in
CEC Drawer
All Processor Cards U1.1-P1-C1 x2 00-00 Connector M03 and
M04 in CEC Drawer
Bus Extender Card U1.1-P1.1 Connector M06 in
CEC Drawer
I/O Hub U1.1-P1.1 Connector M06 in
CEC Drawer
I/O Clock (daughter card) U1.1-P1.1.1 Connector M06 in
CEC Drawer
Regulator 1 U1.1-P1-V1 Connector M01 in
CEC Drawer
Regulator 2 U1.1-P1-V1 Connector M01 in
CEC Drawer
Power Distribution Card U1.1-X1
LED Card U1.1-L1
Power Supply 1 U1.1-V1 PP1 in CEC drawer
Power Supply 2 U1.1-V2 PP2 in CEC drawer
Fan 1 U1.1-F1 BP1 in CEC drawer
Fan 2 U1.1-F2 BP2 in CEC drawer
Primary I/O Drawer Locations
Chapter 1. Reference Information 35
