FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
Primary I/O Drawer U0.1
RIO Bus Adapter U0.1-P1.1
RIO Port 0 Connector U0.1-P1.1/Q1
RIO Port 1 Connector U0.1-P1.1/Q2
All RIO Port Connectors U0.1-P1.1
Primary I/O drawer
backplane
U0.1-P1
PCI to PCI bridge 1 U0.1-P1 10-58, 10-5A, 10-5C,
10-5E
PCI slot 1 U0.1-P1/I1 10-58
PCI slot 1 content (card) U0.1-P1-I1 11-08 through 11-0F
or 12-xx or 13-xx
PCI slot 2 U0.1-P1/I2 10-5A
PCI slot 2 content (card) U0.1-P1-I2 14-08 through 14-0F
or 15-xx or 16-xx
PCI slot 3 U0.1-P1/I3 10-5C
PCI slot 3 content (card) U0.1-P1-I3 17-08 through 17-0F
or 18-xx or 19-xx
PCI slot 4 U0.1-P1/I4 10-5E
PCI slot 4 content (card) U0.1-P1-I4 1A-08 through 1A-0F
or 1B-xx or 1C-xx
PCI to PCI bridge 2 U0.1-P1 20-58, 20-5A, 20-5B,
20-5C, 20-5E
PCI slot 5 U0.1-P1/I5 20-58
PCI slot 5 content (card) U0.1-P1-I5 21-08 through 21-0F
or 22-xx or 23-xx
PCI slot 6 (5V) U0.1-P1/I6 20-5A
PCI slot 6 content (card) U0.1-P1-I6 24-08 through 24-0F
or 25-xx or 26-xx
PCI slot 7 (5V) U0.1-P1/I7 20-5B
PCI slot 7 content (card) U0.1-P1-I7 27-08 through 27-0F
or 28-xx or 29-xx
PCI slot 8 U0.1-P1/I8 20-5C
PCI slot 8 content (card) U0.1-P1-I8 2A-08 through 2A-0F
or 2B-xx or 2C-xx
PCI slot 9 U0.1-P1/I9 20-5E
PCI slot 9 content (card) U0.1-P1-I9 2D-08 through
2D-0F
or 2E-xx or 2F-xx
PCI to PCI bridge 3 U0.1-P1 20-60, 20-62, 20-63,
20-64, 20-66
PCI slot 10 U0.1-P1/I10 20-60
PCI slot 10 content (card) U0.1-P1-I10 31-08 through 31-0F
or 32-xx or 33-xx
36 Service Guide
