FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
PCI slot 11 (5V) U0.1-P1/I11 20-62
PCI slot 11 content (card) U0.1-P1-I11 34-08 through 34-0F
or 35-xx or 36-xx
PCI slot 12 (5V) U0.1-P1/I12 20-63
PCI slot 12 content (card) U0.1-P1-I12 37-08 through 37-0F
or 38-xx or 39-xx
PCI slot 13 U0.1-P1/I13 20-64
PCI slot 13 content (card) U0.1-P1-I13 3A-08 through 3A-0F
or 3B-xx or 3C-xx
PCI slot 14 U0.1-P1/I14 20-66
PCI slot 14 content (card) U0.1-P1/I14 3D-08 through
3D-0F
or 3E-xx or 3F-xx
PCI bus controller 0 U0.1-P1 00-FFF7F08000
PCI bus controller 1 U0.1-P1 00-FFF7F09000
PCI bus controller 2 U0.1-P1 00-FFF7F0A000
ISA Bus U0.1-P1 10-80
Service Processor U0.1-P1
JTAG Connector U0.1-P1/Q4
NVRAM U0.1-P1
Service Processor ISA
Bridge
U0.1-P1
Real Time Clock (RTC) U0.1-P1
Timer U0.1-P1
Interrupt Controller U0.1-P1
DMA Controller U0.1-P1
Diskette controller U0.1-P1-D1 01-D1
Diskette drive U0.1-P1/D1 01-D1-00-00
Keyboard controller /
connector
U0.1-P1/K1 01-K1-00
Keyboard U0.1-P1/K1 01-K1-00-00
Mouse controller U0.1-P1/K1 01-K1-01
Mouse connector U0.1-P1-01 01-K1-01
Mouse U0.1-P1-01 01-K1-01-00
Parallel port connector U0.1-P1/R1 01-R1
Serial port 1 connector U0.1-P1/S1 01-S1
Serial port 2 connector U0.1-P1/S2 01-S2
Serial port 3 connector U0.1-P1/S3 01-S3
Serial port 4 connector U0.1-P1/S4 01-S4
Thermal sensor (ambient) U0.1-L1
Thermal sensor (left) U0.1-P1
Chapter 1. Reference Information 37
