IBM RS/6000 Enterprise Server M80 - Page 56

FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
Thermal sensor (right) U0.1-P1
Ethernet controller /
connector
U0.1-P1/E1 40-58
Internal SCSI controller U0.1-P1/Z1 40-60
External SCSI controller U0.1-P1/Z2 40-61
Tape drive U0.1-P1-Z1-A0 40-60-00-0,0
CD drive U0.1-P1-Z1-A1 40-60-00-1,0
Internal DASD 1 U0.1-P1-Z1-A4 40-60-00-4,0
Internal DASD 2 U0.1-P1-Z1-A8 40-60-00-8,0
SPCN controller U0.1-P1
VSCOM connector U0.1-P1/Q1
Primary I/O drawer
operator panel
U0.1-L1
System VPD Module U0.1-L1-N1
Battery U0.1-P1-V3
Power Distribution Board U0.1-X1
PDB Power Connector 1 U0.1-X1/V1
PDB Power Connector 2 U0.1-X1/V2
Fan Controller Card U0.1-X2
Power Supply 1 (w/Fan 5) U0.1-V1 PDB connector J2
Power Supply 2 (w/Fan 6) U0.1-V2 PDB connector J1
Fan 1 U0.1-F1 Fan connector P3 on
power supply 1
Fan 2 U0.1-F2 Fan connector P3 on
power supply 1
Fan 3 U0.1-F3 Fan connector P3 on
power supply 2
Fan 4 U0.1-F4 Fan connector P3 on
power supply 2
Cooling unit (w/fan 9) U0.1-F9 In cooling unit
System firmware U0.1-P1/Y1
Secondary I/O Drawer 2 Locations
Secondary I/O Drawer U0.2
RIO Bus Adapter U0.2-P1.1
RIO Port 0 Connector U0.2-P1.1/Q1
RIO Port 1 Connector U0.2-P1.1/Q2
All RIO Port Connectors U0.2-P1.1
Secondary I/O drawer
backplane
U0.2-P1
PCI to PCI bridge 1 U0.2-P1 50-58, 50-5A, 50-5C,
50-5E
PCI slot 1 U0.2-P1/I1 50-58
38 Service Guide
