FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
PCI slot 2 U0.4-P1/I2 D0-5A
PCI slot 2 content (card) U0.4-P1-I2 D4-08 through
D4-0F
or D5-xx or D6-xx
PCI slot 3 U0.4-P1/I3 D0-5C
PCI slot 3 content (card) U0.4-P1-I3 D7-08 through
D7-0F
or D8-xx or D9-xx
PCI slot 4 U0.4-P1/I4 D0-5E
PCI slot 4 content (card) U0.4-P1-I4 DA-08 through
DA-0F
or DB-xx or DC-xx
PCI to PCI bridge 2 U0.4-P1 E0-58, E0-5A,
E0-5B, E0-5C,
E0-5E
PCI slot 5 U0.4-P1/I5 E0-58
PCI slot 5 content (card) U0.4-P1-I5 E1-08 through E1-0F
or E2-xx or E3-xx
PCI slot 6 (5V) U0.4-P1/I6 E0-5A
PCI slot 6 content (card) U0.4-P1-I6 E4-08 through E4-0F
or E5-xx or E6-xx
PCI slot 7 (5V) U0.4-P1/I7 E0-5B
PCI slot 7 content (card) A0.4-P1-I7 E7-08 through E7-0F
or E8-xx or E9-xx
PCI slot 8 A0.4-P1/I8 E0-5C
PCI slot 8 content (card) U0.4-P1-I8 EA-08 through
EA-0F
or EB-xx or EC-xx
PCI slot 9 U0.4-P1/I9 E0-5E
PCI slot 9 content (card) U0.4-P1-I9 ED-08 through
ED-0F
or EE-xx or EF-xx
PCI to PCI bridge 3 U0.4-P1 E0-60, E0-62, E0-63,
E0-64, E0-66
PCI slot 10 U0.4-P1/I10 E0-60
PCI slot 10 content (card) U0.4-P1-I10 F1-08 through F1-0F
or F2-xx or F3-xx
PCI slot 11 (5V) U0.4-P1/I11 E0-62
PCI slot 11 content (card) U0.4-P1-I11 F4-08 through F4-0F
or F5-xx or F6-xx
PCI slot 12 (5V) U0.4-P1/I12 E0-63
PCI slot 12 content (card) U0.4-P1-I12 F7-08 through F7-0F
or F8-xx or F9-xx
PCI slot 13 U0.4-P1/I13 E0-64
Chapter 1. Reference Information 43
