FRU Name
Location
Code
AIX
Location
Code
Physical
Connection
Logical
Connection
PCI slot 13 content (card) U0.4-P1-I13 FA-08 through FA-0F
or FB-xx or FC-xx
PCI slot 14 U0.4-P1/I14 E0-66
PCI slot 14 content (card) U0.4-P1/I14 FD-08 through
FD-0F
or FE-xx or FF-xx
PCI bus controller 1 U0.4-P1 00-FFF7C09000
PCI bus controller 2 U0.4-P1 00-FFF7C0A000
SPCN controller U0.4-P1
External SCSI connector U0.4-P1/Z1
Secondary I/O drawer
VPD module
U0.4-L1-N1
Thermal sensor (ambient) U0.4-L1
Thermal sensor (left) U0.4-P1
Thermal sensor (right) U0.4-P1
Power distribution board U0.4-X1
PDB power connector 1 U0.4-X1/V1
PDB power connector 2 U0.4-X1/V2
Fan controller card U0.4-X2
Power supply 1 (w/Fan 5) U0.4-V1 PDB connector J2
Power supply 2 (w/Fan 6) U0.4-V2 PDB connector J1
Fan 1 U0.4-F1 Fan connector P3 on
power supply 1
Fan 2 U0.4-F2 Fan connector P3 on
power supply 1
Fan 3 U0.4-F3 Fan connector P3 on
power supply 2
Fan 4 U0.4-F4 Fan connector P3 on
power supply 2
Cooling unit (w/fan 9) U0.4-F9 In cooling unit
SPCN firmware U0.4-P1/Y3
SPCN VPD U0.4-P1/Y4
SCSI Device Locations
SCSI Adapter
x = drawer number
y = PCI slot number
z = connector
U0.x-P1-ly-Zz AB-CD
Where AB-CD
identifies the
adapter’s slot
Bus ID 15
Media Device (Bay A1 or
A2) When connected to
PCI adapter in slot
U0.x-P1-ly
x = drawer number
y = PCI slot number
z = connector
U0.x-P1-ly-Zz-Ai AB-CD-00-15, 0
Where AB-CD
identifies the
adapter’s slot
Bus ID 15
44 Service Guide
