5. From one side of the rack cabinet, grip the rail and slide the rail pieces
together to shorten the rail.
6. Disengage the rail location pins î2î.
7. From the other side the rack cabinet, grip the rail and slide the rail pieces
together to shorten the rail.
8. Disengage the rail location pins î2î.
9. Starting from the location of the previous rail assembly, align the bottom of
the rail with the bottom of the two rack units. Insert the rail location pins
through the holes in the rack cabinet.
10. Insert a clamping screw into the upper mounting hole between the rail
location pins.
11. Tighten the screw to secure the rail to the rack.
12. Working from the rear of the rack cabinet, extend the rail that you secured to
the front to align the bottom of the rail with the bottom of the two rack units.
Note: Ensure that the rail is level between the front and the back.
13. Insert the rail location pins through the holes in the rack cabinet.
14. Insert a clamping screw into the upper mounting hole between the rail
location pins.
15. Tighten the screw to secure the rail to the rack from the back side.
16. Repeat the steps to secure the opposite rail to the rack cabinet.
Storwize V7000 replaceable units
TheStorwize V7000 consists of several replaceable units. Generic replaceable units
are cables, SFP transceivers, canisters, power supply units, battery assemblies, and
enclosure chassis.
Table 22 provides a brief description of each replaceable unit.
Table 22. Replaceable units
Part Part number
Applicable
models
FRU or customer
replaced
2U24 enclosure chassis (empty
chassis)
85Y5897 124, 224, 324 FRU
2U12 enclosure chassis (empty
chassis)
85Y5896 112, 212, 312 FRU
Type 100 node canister 85Y5899 112, 124 Customer
replaced
Type 300 node canister with 10
Gbps Ethernet ports
85Y6116 312, 324 Customer
replaced
Expansion canister 85Y5850 212, 224 Customer
replaced
764 W power supply unit 85Y5847 112, 124, 312, 324 Customer
replaced
580 W power supply unit 85Y5846 212, 224 Customer
replaced
Battery backup unit 85Y5898 112, 124, 312, 324 Customer
replaced
1 m SAS cable 44V4041 212, 224 Customer
replaced
Chapter 8. Removing and replacing parts 109
|
