USB connector pin assignments
SureMark printers contain a USB port, if the USB feature is installed. This port is on
the interface card, accessible under the printer without removing printer covers.
Connection to the port can be with either the standard USB Type B connector,
which requires a 24 V power brick, or with the powered USB connector, which
contains 24 V power lines within the communications cable.
The standard USB Type B connector has the following pin functions:
Table 11. Standard USB connector pin assignments
Pin Signal
1 Vbus (+5 V dc)
2 Minus data
3 Plus data
4 Ground
The powered USB connector has the following pin functions:
Table 12. Powered USB connector pin assignments
Pin Signal
1 Ground (+24 V dc)
2 +24Vdc
3 Ground (Vbus)
4 Plus data
5 Minus data
6 Vbus +5 V dc
7 +24Vdc
8 Ground (+24 V dc)
See “Description of models” on page 4 for the cable part numbers.
Code page definitions
The SureMark printer has a resident character set that supports these code pages:
v Generic
v 437 (US)
v 850 (International) – Models TI1 and TI2 only
v 858 (International) – Models TI3, TI4, TI8, TI9, TG3, TG4, TG8, TG9, TF6 and
TM6
v 860 (Portuguese)
v 863 (Canadian French)
v 865 (Norwegian)
Note: Code page 850 contains all characters from code page 858, except the
EURO character.
Four user-defined character sets for thermal printing and two character sets for
impact printing can be downloaded, if desired, using the 4610 Installation Utility
Diskette. See “Resources on the Internet” on page 44 for more information.
Updated April 2, 2009
92 SureMark Printers User’s Guide
