Table 3. Parts listing, Type 7977 (continued)
Index Description
CRU
part number
(Tier 1)
CRU
part number.
(Tier 2)
FRU
part number
6 Hard disk drive, 250 GB (option) 39M4529
6 Hard disk drive, 300 GB (option) 39R7344
6 Hard disk drive, 500 GB (option) 39M4533
7 Bezel 44E3223
7 Bezel, SFF filler assembly (models E8x, J2x, L2x, ) 26K8680
8 Hard disk drive filler 41Y9043
9 SAS hard disk drive backplane 44E8783
9 Hard disk drive backplane (models J2x, L2x) 43X0334
9 Hard disk drive backplane (models E8x, E9x, J2x, L2x) 46C6425
10 Fan cage, front 41Y9067
11 Fan assembly , 120 mm top cover (models CTO, E3x,
E6x, E8x, E9x, EFx, EGx)
44E4563
12 Microprocessor duct 39Y8501
13 System board with tray 44R5619
13 Tray, system board 41Y9077
14 ServeRAID-8k with battery pack 44E8732
15 Power supply VRM (model CTO) 24R2694
16 Light Path Diagnostic panel assembly 39Y7125
17 Left-side cover 39Y8362
18 Microprocessor baffle (models 12x, 22x, 42x, 52x, 62x,
72x, 82x, 92x, A2x, B2x, C2x, D2x, E1x, E2x, E3x, E4x,
E5x, E6x, E7x, E8x, EFx, EGx, F2x, G2x, H2x, J2x, L2x,
M2x, Q4x, R2x)
39M6800
19 Heat sink 40K7438
20 Microprocessor, 1.6 GHz (models 42x, E1x, E2x) 41Y4275
20 Microprocessor, 1.6 GHz, quad core, 80 watt (model B2x) 43W5174
20 Microprocessor, 1.86 GHz, quad core, 80 watt (model
C2x)
43W5175
20 Microprocessor, 1.87 GHz (model 52x) 41Y4276
20 Microprocessor, 2.0 GHz (models 62x, E6x) 41Y4277
20 Microprocessor, 2.0 GHz, quad core, 80 watt (models F2x,
EFx)
43W5182
20 Microprocessor, 2.0 GHz, quad core, 80 watt, with heat
sink (model A2x)
44R5644
20 Microprocessor, 2.33 GHz (models 72x, E4x) 41Y4278
20 Microprocessor, 2.33 GHz, quad core, 80 watt (models
G2x, EGx)
43W5183
20 Microprocessor, 2.33 GHz, quad core, 80 watt, with heat
sink (model D2x)
44R5645
20 Microprocessor, 2.5 GHz, quad core, 80 watt, with heat
sink (models E7x, EBx, J2x)
44R5646
Chapter 3. Parts listing, System x3500 Type 7977 43
