Table 3. Parts listing, Type 7977 (continued)
Index Description
CRU
part number
(Tier 1)
CRU
part number.
(Tier 2)
FRU
part number
20 Microprocessor, 2.66 GHz, quad core, 120 watt (model
H2x)
43W5184
20 Microprocessor, 2.66 GHz, quad core, 80 watt, with heat
sink (models E8x, L2x)
44R5647
20 Microprocessor, 2.67 GHz (models 82x, E5x) 41Y4279
20 Microprocessor, 2.83 GHz, quad core, 80 watt, with heat
sink (model E3x, M2x)
44R5648
20 Microprocessor, 3.0 GHz (model 92x) 41Y4280
20 Microprocessor, 3.0 GHz (model 12x) 41Y8905
20 Microprocessor, 3.0 GHz, quad core, 120 watt (model
E9x, R2x)
44E5117
20 Microprocessor, 3.2 GHz (model 22x) 41Y4223
20 Microprocessor, 3.16 GHz, quad core, (model Q4x) 46C7740
20 Microprocessor, 3.33 GHz, dual core, without heat sink
(option)
46C7742
20 Microprocessor, 3.33 GHz, quad core, without heat sink
(option)
46M1028
21 Retention module, microprocessor 39M6783
22 Memory, 512 MB PC5300 ECC (models 12x, 22x, 42x,
52x, 62x, 72x, 82x, 92x, A2x, B2x, C2x, D2x, E1x, E4x,
E5x, F2x, G2x, H2x, J2x, L2x, M2x, Q4x, R2x)
39M5781
22 Memory, 1 GB PC5300 ECC (models E2x, E6x, E7x, EFx) 39M5784
22 Memory, 1 GB DDRR (option) 46C7421
22 Memory, 2 GB PC5300 ECC (models E3x, E8x, EBx,
EGx, E9x)
39M5790
22 Memory, 2 GB DDRR (option) 46C7422
22 Memory, 4 GB PC5300 ECC (option) 41Y2845
22 Memory, 4 GB DDRR (option) 46C7423
23 Remote Supervisor Adapter II SlimLine Bracket 41Y9086
24 DIMM air duct 39Y8499
25 Power supply cage 24R2738
26 Filler panel, power supply (models 12x, 22x, 42x, 52x,
62x, 72x, 82x, 92x, A2x, B2x, C2x, D2x, E1x, E2x, E3x,
E4x, E5x, E6x, E7x, E8x, E9x, EBx, EFx, EGx, F2x, G2x,
H2x, J2x, L2x, M2x, Q4x, R2x)
39Y7391
Alcohol wipe 59P4739
Adapter, 3U SCSI (option) 43W4325
Adapter, NetXtreme1000 (option) 39Y6081
Adapter, NetXtreme SXG (option) 39Y6090
Adapter, NetXtreme dual (option) 39Y6095
Adapter, NetXtreme TXG (option) 39Y6100
Adapter, iSCSI TX server (option) 30R5209
44 IBM System x3500 Type 7977: Problem Determination and Service Guide
