IBM ThinkPad 600 User Manual

Using the Audio Features
Your computer is equipped with the following:
A -inch (3.5-mm) diameter external stereo line-in or monaural
microphone/line-in jack.
Note
To use the input jack for an external stereo line-in device,
you need to disable the microphone function with software on
your operating system. For example in Windows 95, you can
disable the function by putting a check mark in the check box
of Mute for MIC in the “Master Out” window. To use the jack
for a manual microphone, disable the line-in function with
software.
A -inch (3.5-mm) diameter stereo headphone or an
external-powered speaker jack.
A MIDI/joystick port on the docking station. To use a MIDI
device, you should first connect your computer to the &dosk.;
then connect an external MIDI device to the docking station.
After docking your computer in the docking station, you should
enable this port using the ThinkPad Configuration program.
Your computer also has an audio chip that enables you to enjoy
various multimedia audio features. This audio chip provides the
following features:
Recording and playing back of PCM and WAV files in 8-bit or
16-bit format.
Sampling of various rates from 8 KHz to 44 KHz for the WAV
file.
Playback of MIDI files through an FM synthesizer.
Recording from various sound sources, such as an integrated
microphone, an external microphone, or an audio device
attached to a line-in jack or an integrated CD-ROM drive.
DOS game compatibility. You should select Sound Blaster Pro**
for the audio adapter in the sound setup of the game.
6
IBM ThinkPad 600 Online Book

IBM ThinkPad 600 Specifications

General

Processor	Intel Pentium II
Graphics	Neomagic MagicGraph128XD
Operating System	Windows 95, Windows 98, or Windows NT 4.0
Resolution	800 x 600
Battery	Lithium-Ion
Optical Drive	Optional external CD-ROM drive
Ports	Serial, Parallel, VGA
Network	10/100 Ethernet
Clock Speed	233 MHz to 300 MHz
Display	12.1-inch TFT
