Using a docking station
9
Click the IDE Device tab.
10
Select Enable in the UltraBay IDE device in the
docking station list box.
The third IDE is automatically selected.
11
Select Second in the IDE Channel list box.
12
Click Disable Devices in the warning dialog box.
13
Click OK to close the dialog box.
14
Restart the system by clicking OK in the warning dialog
box.
The following table shows how the devices are related to the IRQ
values:
Legend:
1. P-M: Primary-master
2. P-S: Primary-slave
3. S-M: Secondary-master
4. S-S: Secondary-slave
5. T-M: Third-master
6. T-S: Third-slave
Though the name of the list box uses the term
UltraBay
,
it refers to your UltraslimBay.
Device 2-channel IDE
default mode
3-channel IDE
mode
2-channel IDE
mode
Hard disk
drive
IRQ 14, P-M IRQ 14, P-M IRQ 14, P-M
UltraslimBay IRQ 15, S-M IRQ 15, S-M IRQ 14, P-S
Docking
station
Disabled IRQ 11, T-M
and T-S
IRQ 15, S-M
and S-S
Chapter 2. Extending the features of your computer 87
