Increasing memory
To avoid damaging the DIMM, do
not touch its contact edge.
4
Find the notch on the side of the DIMM.
5
With the notched end of the DIMM toward the socket,
insert the DIMM, at an angle of about 25°, into the
socket; then press it firmly .1/.
6
Pivot the DIMM until it snaps into place .2/.
1
2
Notch
Side view
1
2
Chapter 2. Extending the features of your computer 51
