Feature Code Description
7010 Deskside Kit
8002 LTO Cleaning Cartridge
8111 Extra Cartridge Magazine
8905 Ultrium 9 Data Cartridges (5-pack)
8806 Ultrium 8 Data Cartridges (5-pack)
8706 Ultrium 7 Data Cartridges (5-pack)
9800-9847 Power cords
For the list of replacements parts, see Replacement parts.
Installing
Installation Precautions
Do not expose the library to moisture.
Do not place the library on either the ends or sides as this action might cause damage.
To install and configure a tabletop or rack-mounted TS2900 Tape Autoloader, complete these procedures in the order they are presented.
Identifying library components
Use the packing slip that is included with your library to identify the library components.
Installing on a tabletop
Follow the directions for installing the deskside cover, if the library is used as a tabletop unit.
Installing in a rack
The TS2900 Tape Autoloader can be easily installed into a standard 19-inch rack system.
Removing the accessor locking screw
Connecting cables
Steps to connect the Ethernet and SAS cables.
Powering on the library
Steps to power on the library.
Initial configuration and customization
Labeling and loading tape cartridges
The procedure for loading the library with cartridges.
Verifying the installation
To verify the installation, follow the steps:
Verifying the host connection
Procedure to verify the connection between the host computer and the library.
Registering for support notification
Support notification registration provides email notification when new firmware levels are updated and are available for download and installation.
Identifying library components
Use the packing slip that is included with your library to identify the library components.
The TS2900 model 3572 is not shipped with the rack mount kit (IBM FC: 7006) and/or power cord (IBM FC: 9800-9847) unless it is ordered.
1. Locate one or more packing slips.
2. Verify that you received each item that is listed on the packing slips.
You must provide SAS cabling with the correct configuration for your HBA. See Optional features.
Note: Order the power cord that matches the electrical requirements of the country or area. See Power cords and receptacles.
Important: If any of the contents of your shipment are damaged or missing, call the appropriate number that is listed on the Quality Hotline card.
Installing on a tabletop
Follow the directions for installing the deskside cover, if the library is used as a tabletop unit.
A deskside cover and six desktop feet must be installed on the library chassis before the library can be used as a tabletop unit. If you intend to install the library in a rack,
skip this step and proceed to Installing in a rack.
Table 1 lists the parts in the deskside assembly kit. A Phillips head screwdriver (preferably with a magnetic head) is needed to assemble the deskside kit.
Table 1. Deskside Assembly Kit
Number Part Number Quantity Description Part
1 45E3240 6 1U desktop foot
2 45E3798 1 Deskside cover
