Figure 93. Leader pin in the incorrect and correct positions
To reposition the leader pin:
1. Slide open the cartridge door ( 1 in Figure 94 on page 167) and locate the leader pin 2 (you might
need to shake the cartridge gently to roll the pin toward the door).
2. With plastic or blunt-end tweezers, grasp the leader pin and position it in the pin-retaining spring clips
3 .
3. Press the leader pin gently into the clips until it snaps into place and is îš³rmly seated.
4. Close the cartridge door.
Figure 94. Placing the dislodged leader pin into the correct position
5. To rewind the tape, insert the cartridge manual rewind tool ( 1 in Figure 95 on page 168) into the
cartridge's hub 2 and turn it clockwise until the tape becomes taut.
Appendix B. LTO media
167
