Thumbscrew
Fan door
4. Close the fan door.
5. Slide the server all the way into the rack until it latches.
Removing the air baffle
When working with some options, such as DIMMs, you must first remove the air
baffle to access certain components or connectors on the system board. The
following illustration shows how to remove the air baffle.
To remove the air baffle, complete the following steps.
Chapter 4. Removing and replacing server components 43
