111
OPTIONS
16
AH-4 HF AUTOMATIC ANTENNA TUNER
Specially designed to tune a long wire
antenna for HF/50 MHz bands partic-
ularly in portable or mobile operation.
The “PTT tune” function provides sim-
ple operation.
s)NPUTPOWERRATING7
AH-2b ANTENNA ELEMENT
A 2.5 m long antenna ele-
ment for mobile operation
with the AH-4.
s&REQUENCY COVERAGE
7–54 MHz band with the
AH-4
SM-30 DESKTOP MICROPHONE
Unidirectional, electret microphone for
base station operation. Includes low
cut switch and mic gain control.
SM-50 DESKTOP MICROPHONE
Unidirectional, dynamic microphone for
base station operation. Includes [UP]/
[DOWN] switches, a low cut switch and
mic gain control.
SP-23 EXTERNAL SPEAKER
4 audio filters; headphone jack; can
connect to 2 transceivers.
s)NPUTIMPEDANCEø
s-AXINPUTPOWER7
HM-36 HAND MICROPHONE
Hand microphone equipped with [UP]/
[DOWN] switches.
The same as that attached with the
transceiver.
IC-PW1/EURO HF/50 MHz ALL BAND 1 kW LINEAR AMPLIFIER
Full-duty 1 kW linear amplifier including an automatic antenna tuner. Has auto-
matic tuning and band selection capability. Full break-in (QSK) operation is pos-
sible. The amplifier/power supply unit and the remote control unit are separated.
The optional OPC-599
ADAPTER CABLE is required for connection.
PS-126 DC POWER SUPPLY
s/UTPUTVOLTAGE6$#
s-AXOUTPUTCURRENT!
N/PTIONS
FL-430 1ST IF FILTER (6 kHz)
FL-431 1ST IF FILTER (3 kHz)
These filters reduce interference
from strong nearby signals.
SP-21 EXTERNAL SPEAKER
Designed for base station operation.
s)NPUTIMPEDANCEø
s-AXINPUTPOWER7
CT-17 CI-V LEVEL CONVERTER UNIT
For remote transceiver control using a
personal computer equipped with an
RS-232C port. You can change fre-
quencies, operating mode, memory
channels, etc., via your computer.
