3
Terminal mode operation
15
■ Setting the Terminal mode
DWhen using the ID-31A/E PLUS, ID-51A/E (PLUS2), ID-52A/E, ID-50A/E
L In this document, the ID-52A/ID-52E is used as an example.
[Transceiver operation]
1. Push [MENU].
[Windows or Android operation]
L When using the RS-MS3A application, select “USB” in
the RS-MS3A “Connection.”
z Click (touch) <Start> in the RS-MS3W or
RS-MS3A.
L If an error message is displayed, see page 16 to
read the tips to solve the problem.
“TM” is displayed
when using the
ID-31A PLUS/
ID-31E PLUS.
2. Select “DV Gateway.”
3. Select “<<Terminal Mode>>.”
TIP: Canceling the Terminal mode
[Windows or Android operation]
1. Click (touch) <Stop>
in the RS-MS3W or RS-MS3A.
[Transceiver operation]
2. Select “<<Normal Mode>>” in the Quick Menu or “DV Gateway” on the MENU screen.
L To display the Quick Menu, push [QUICK].
NOTE: In the Terminal mode
• The Power Save function and the Time Out Timer function are not activated.
• The Following items are automatically set.
ID-31A PLUS/ID-31E PLUS ID-51A (PLUS2)/ID-51E (PLUS2)/ID-52A/ID-52E/ID-50A/ID-50E
Receive mode: DV mode Receive mode: DV mode
DR function: ON* DR function: ON (MAIN band)*
FROM: MY Call Sign FROM: MY Call Sign
Dualwatch function: OFF*
* These settings do not return to the previous settings even if you cancel the Terminal mode.
• The Terminal mode is not automatically canceled even if you turn OFF the transceiver, then ON it again.
When using the UDP Hole Punch function
Set “UDP Hole Punch” to “ON” in the RS-MS3W or
RS-MS3A. (p. 8)
TouchClick
