6
TROUBLESHOOTING
82
NOTE:
If you could not solve the problem after trying the solutions described on the previous page, check the following
on the Base station side.
When connecting to the network through a PC
• Is the volume level of the audio device to which the radio is connected set to an appropriate level?
When connecting to the network directly
• Is the “Network AF” items set to an appropriate level in the Others set mode?
Problem: The transmit audio cannot be output
- The description in this part is based on the assumption that the connection to the radio has succeeded.
(“<<Connected>>” is displayed under the radio name).
- To check the Remote station’s transmit IF signals, use the Transmit Monitor function with the Base station’s
Remote Utility, or place a receiver near the Remote station’s or Base station’s PC.
Possible cause 1
The microphone is not turned ON, or the input level is too low.
Solution
Turn the microphone ON and adjust the input level.
Possible cause 2
The appropriate audio device is not selected in the Remote Utility.
Solution
Select the appropriate audio device in the Mic menu in the Connection Setting screen.
(Radio List screen ➔ <Settings>) (pp. 36, 65)
If you connect a new USB audio device to your PC, the audio device which is selected as a default
device in your PC can be changed. If you select “Default Device” in the Mic menu, please keep that
in mind.
Possible cause 3
The input level of the audio device is set to too low on your PC.
Solution
Adjust the input level of the audio device. (pp. 6 to 11)
Possible cause 4
Audio input is disabled in the Remote Utility.
Solution
Insert a check mark in the MOD Transmission box in the Connection Setting screen.
(Radio List screen ➔ <Settings>)
Possible cause 5
The input level is too low in the Remote Utility.
Solution
Adjust the input level in the Transmit Audio Adjustment screen.
(Radio List screen ➔ <MOD>) (p. 67)
Possible cause 6
An incorrect connector is selected in the Remote Controller.
Solution
Select the proper radio’s connector which is connected to the Base station’s PC, in the MOD Select
(Remote ON) menu in the Remote Controller’s MIC SET screen. (p. 74)
NOTE:
If you could not solve the problem after trying the above solutions, check the following on the Base station side.
When connecting to the network through a PC
• Is the input level of the audio device to which the radio is connected set to an appropriate level?
When connecting to the network directly
• Is the “Network MOD” items set to an appropriate level in the Others set mode?
To Next Page
