Icom rs-ba1 - Step 3: Setting Network Function on Radio

Installtion guide B
B-4
In this guide, explains how to set the radio for
operating the remote control system through the LAN.
When using the remote control system using the
Internet, read the RS-BA1 Instruction Manual
(“3. WHEN CONNECTING TO THE NETWORK
DIRECTLY” section).
This section describes how to setup the Base station.
Before conguring the settings, turn ON the radio.
To prevent unauthorized access:
Set a long and strong password so that no one can
possibly guess it.
Mix upper and lower case letters, numbers or
characters.
• Except for the IC-7610
1. Hold down [EXIT/SET] for 1 second to select the
Set mode menu screen.
2. Push [OTHERS](F-5) to enter the Others set
mode.
3. Push [▲](F-1) or [▼](F-2) to select the desired
item.
• See page B-5 for the setting items.
4. Adjust/select or enter the needed contents.
• See page B-5 for the setting contents.
• Hold down [DEF](F-4) for 1 second to return them to
their defaults.
• See the RS-BA1 Instruction Manual for details.
5. Push [EXIT/SET] to exit the Set mode.
NOTE: When you change the setting that
shows “(Valid after Reboot),” you have to reboot
the radio after setting, so they will take effect.
• After the reboot, keep the radio’s power ON,
or remain in the remote standby mode.
• For the IC-7610
1. Push [MENU] to display the MENU screen.
2. Touch [SET] to enter the Set mode.
3. Touch the category that you want to select.
4. Touch the item to open the item’s setting screen,
or open its next tree level.
• See page B-5 for the setting items.
5. Touch to select or set the option.
• See page B-5 for the setting contents.
• Push [QUICK] and touch “Default” to return them to
their defaults.
• See the RS-BA1 Instruction Manual for details.
6. Push [MENU] to exit the Set mode.
NOTE: When you change the setting that
shows “(Valid after Restart),” you have to restart
the radio after setting, so they will take effect.
• After the restart, keep the radio’s power ON,
or remain in the remote standby mode.
Step3. Setting the Network function on the radio
1. 2. Step3. 4. 5.
