Icom rs-ba1 - Page 18

Installtion guide B
B-5
[Setting items and contents]
• Network setting
(Except for the IC-7851, IC-7850, and IC-7610)
Items Contents
Network Control
OFF (Default)  ON
IP Address IP address that is not assigned to
any other device.
Example: 192.168.0.10
(Default)
Default Gateway IP address of the LAN side on
the router
Example: 192.168.0.1
Control Port (UDP) 50001 (Default)
Serial Port (UDP) 50002 (Default)
Audio Port (UDP) 50003 (Default)
Internet Access Line Your internet access line type
Example: FTTH (Default)
• Network setting
(For the IC-7851, IC-7850, and IC-7610)
Items Contents
Network Control
OFF (Default)  ON
DHCP* ON (Default)
Network Name* Desired Network Name
Example: IC-7851
Control Port (UDP) 50001 (Default)
Serial Port (UDP) 50002 (Default)
Audio Port (UDP) 50003 (Default)
Internet Access Line Your internet access line type
Example: FTTH (Default)
* If you are setting the IP address instead of the network radio
name, set the DHCP item to OFF. For the other settings, see
“Network setting (Except for the IC-7851, IC-7850, and IC-7610).”
• Radio registration
Items Contents
Network Radio Name Desired Network Radio Name
• Up to 16 characters
Example: IC-7851abc
CI-V Address Desired CI-V Address
Example: the radios’ default
setting.
IC-7851/IC-7850: 8Eh
IC-7800: 6Ah
IC-7700: 74h
IC-7610: 98h
CI-V Baud Rate Desired Baud Rate
Example: Auto (Default)
• User registration
Items Contents
Network User1/2/3*
ID
Desired User ID
• Up to 16 characters
Example: USER1
Network User1/2/3*
Password
Desired Password
• 8 to 16 characters
• At least two different characters
must be used.
Example: USER0001
Network User1/2/3*
Administrator
NO (Default)  YES
• In case the user is set as an
administrator.
* When using IC-7610, Network User3 is not used.
• Transmitting audio setting
(For the IC-7800 and IC-7700)
Items Contents
Network MOD Use ON (Default)
1. 2. Step3. 4. 5.
Step3. Setting the Network function on the radio (Continued)
