PRT-CTRL-SE Protege SE Integrated System Controller Installation Manual | June 2017 35
12 System Capacities
The Protege Controller can be profiled to allow a comprehensive solution that allows optimal performance to be
achieved in any installation.
Standard Access Elevator School Storage Automation Apartment
Users 2000 10000 2000 2000 500 2000 2000
User Names 2000 2000 0 2000 500 2000 2000
Events 2000 4000 2000 4000 4000 1000 2000
Areas 32 32 64 64 128 64 248
Doors 16 128 64 16 16 64 4
Keypad Modules 32 16 8 8 8 32 48
Analog Expanders 8 8 8 8 8 16 8
Zone Expanders 16 8 4 32 64 8 4
Reader Expanders 8 64 32 16 8 32 4
Output Expanders 8 8 8 8 32 8 2
Zone Inputs 464 720 368 688 624 528 1104
Trouble Zone Inputs 704 1408 800 768 832 1088 2224
PGM Outputs 420 772 468 452 772 612 1108
PGM Groups 128 128 28 28 248 128 128
Area Groups 32 32 64 64 248 64 248
Menu Groups 16 16 16 16 16 16 16
Door Groups 128 248 28 32 16 16 16
Keypad Groups 32 16 8 8 8 8 8
Access Levels 128 248 248 32 248 64 16
Zone Types 128 128 32 28 248 64 16
Door Types 8 8 8 8 8 8 4
Services 8 8 8 8 4 8 4
Phone Numbers 16 16 16 16 8 8 8
Schedules 128 248 48 28 64 32 32
Holidays 32 32 32 32 32 32 8
Daylight Saving Adjustment
Settings
1 1 1 1 1 1 1
Automation Points 32 32 32 32 16 248 8
Panel Configuration Information 1 1 1 1 1 1 1
Area Names 32 32 64 64 128 64 248
Access Level Names 128 248 48 32 248 64 16
Zone Type Names 64 64 32 28 248 16 16
Zone Names 464 720 68 88 1136 28 1104
