ICT Protege SE - Current and Validation (UL Installation) Example 1

40 PRT-CTRL-SE Protege SE Integrated System Controller Installation Manual | June 2017
Application
Maximum Total Output
Current Available
Charging Jumper
Setting Transformer Battery Rating
CAN/ULC-S304
24hr backup
100mA 700mA 40VA/100VA 1 x 12VDC, 7Ah
400mA 700mA 40VA/100VA
2 x 12VDC, 7Ah =
14Ah
CAN/ULC-S559
24hr backup
100mA 700mA 100VA 1 x 12VDC, 7Ah
400mA 700mA 100VA
2 x 12VDC, 7Ah =
14Ah
UL 1610, UL
1635 24hr
backup
100mA 700mA 40VA/100VA 1 x 12VDC, 7Ah
400mA 700mA 40VA/100VA
2 x 12VDC, 7Ah =
14Ah
UL 1610, UL
1635 72hr
backup
60mA 350mA or 700mA 40VA/100VA
2 x 12VDC, 7Ah =
14Ah
i
The Maximum Total Output Current Available is the maximum current that can be supplied to the
AUX1/AUX2 DC Outputs and B1/B2 DC Outputs.
These are the maximum current values to ensure compliancy with the standby requirements.

13.4 Current and Validation (UL Installation) Example 1
Using a 40VA Transformer and 14Ah Battery
UL1610, UL1635 (72 hr standby capacity)
External Devices Connected to Panel
1 x PRT-KLCD Protege Alphanumeric LCD Keypad (30mA Typical)
Standby Current Consumption
Total Output Current Available 60mA
DC Output (AUX1) PRT-KLCD Protege Alphanumeric LCD Keypad (30mA Typical)
Total Output Current Consumption 30mA
Current Consumption
Total Combined Current Available 1.7A (1700mA)
Operating Current 120mA (Typical)
Battery Charging 350mA (Standard Current Charging)
DC Output (AUX1) PRT-KLCD Protege Alphanumeric LCD Keypad (30mA Typical)
Total Consumption 0.5A (500mA)
