16.3 UL Compliance Requirements
UL1610
 A local alarm sounding device, alarm housing, and control unit shall comply with the mercantile
requirements in the Standard for Police Station Connected Burglar Alarm Units and Systems, UL365.
 Exit and entry delay must not exceed 60 seconds. To program the entry and exit delay time, please refer to
the section Area in the Protege System Controller Reference Manual (227-4045-500).
 All Ethernet network connections shall be installed within the same room as the equipment.
 Signals between the premises control unit and the receiving equipment, when not carried by wireless
means, shall be protected by the following method:
 Onboard modem telco connection must be dedicated to the PRT-CTRL-SE.
 Ethernet connection to the Internet Service Provider (ISP) with a fixed IP Address must be dedicated to
the PRT-CTRL-SE.
 To comply with the dual signal line transmission system requirement, both transmission lines (onboard
modem and IP reporting) must be enabled. Signals shall be sent simultaneously to both, Report IP Service
and Contact ID Reporting Service.
The Report IP and Contact ID services must be programmed and enabled within the Protege System. The
following options are required:
 The Contact ID Reporting Service must be enabled and the Service Mode must be configured to start
with the operating system.
Refer to the section Contact ID Reporting Service in the Protege System Controller Reference Manual
(227-4045-500)
 The Report IP Service must be enabled as the primary communication channel, the Service Mode
must be configured to start with the operating system, and the Reporting Protocol must be set to
ArmorIP.
Refer to the section Report IP Service in the Protege System Controller Reference Manual
(227-4045-500).
 When more than one means of signal transmission is used, loss of communication with the receiving
system shall be annunciated at the receiver within 200 seconds. If a fault is detected on any of the signal
transmission means, at least one of the signal transmission channels shall send a signal to the
central-station to report the fault within 200 seconds.
The Report IP and Contact ID services must be programmed and enabled within the Protege System.
The PRT-CTRL-SE is compatible with the Integrated Control Technology ArmorIP Internet Monitoring
Receiver. Poll Time must be set to 40 seconds and the Grace Time must be set to 20 seconds.
In the Protege System, the reporting service must be configured to 40 seconds. The following options are
required for the service selected as Report IP type:
 The Enable Poll Events option must be enabled. Please refer to option 5 in the section Reporting
Options in the Protege System Controller Reference Manual (227-4045-500)
 The Poll Time must be programmed to 40 seconds. Please refer to the Poll Time section in the Protege
System Controller Reference Manual (227-4045-500)
 The Contact ID Reporting Service must be enabled and the Service Mode must be configured to start
with the operating system.
Refer to the section Contact ID Reporting Service in the Protege System Controller Reference Manual
(227-4045-500)
 The Report IP Service must be enabled as the primary communication channel, the Service Mode
must be configured to start with the operating system, and the Reporting Protocol must be set to
ArmorIP.
Refer to the section Report IP Service in the Protege System Controller Reference Manual
(227-4045-500).
 The Trouble Zone Area must be armed in 24h mode. Refer to the section 24HR Enabling in the
Protege System Controller Reference Manual (227-4045-500).
