PRT-CTRL-SE Protege SE Integrated System Controller Installation Manual | June 2017 37
13 Technical Specifications
The following specifications are important and vital to the correct operation of the Protege Controller. Failure to
adhere to the specifications will result in any warranty or guarantee that was provided becoming null and void.
Integrated Control Technology continually strives to increase the performance of its products. As a result these
specifications may change without notice. We recommend consulting the ICT website (http://www.ict.co) for the
latest documentation and product information.
Operating Voltage 16 to 16.5VAC secondary (via transformer)
Operating AC Input Current 3.3A @ 16VAC when Total Combined Current = 2.5A
2.2A @ 16.5VAC when Total Combined Current = 1.7A
Operating Current 120mA (Typical)
Total Combined Current 1.7A (Max) using a 37/40VA transformer
2.5A (Max) Using a 60VA or greater transformer
Electronically limited at 2.5A
AUX1/AUX2 DC Outputs 11.0V-12.3V, 1.0A (Typical) Electronic Shutdown at 1.85A
B1/B2 DC Outputs
(Continuous)
11.0V-12.3V, 8 Ohm 30W Siren or 1.1A (Maximum)
B1/B2 DC Outputs (Inrush) 1500mA
Battery Charging 350mA/700mA
Battery Low 11.2VDC
Battery Restore 12.5VDC
Electronic Disconnection 9.4VDC
Communication (Ethernet) 1 10/100Mbps Ethernet Communication Link
Communication (Serial) 1 Isolated RS-485 Communication Interface Port 12VDC @ 28mA. (Input)
Communication (Modem) 1 2400bps Modem Communication
Readers (Standard Mode) 2 Wiegand or clock data readers providing one Entry/Exit Door or two Entry/Exit
only Doors.
Readers (Multiplex-reader
Mode)
4 Wiegand Readers (connected in Multiplex Reader mode) providing any
combination of Entry or Exit for two Doors.
Zone Inputs (System Zones) 16 High Security Monitored Zone Inputs
Tamper Input Dedicated Hardware Tamper Input
PGM Outputs 6 50mA (Max) Open Collector Output for reader LED and beeper or general
functions.
Status Output 1 50mA (Max) Open Collector Output
Operating Temperature 0˚-50˚C (32˚ - 122˚F)
Storage Temperature -10˚- 85˚C (14˚ - 185˚F)
Humidity 0%-93% non-condensing, indoor use only (relative humidity)
Dimensions (L x W x H) 234 x 183 x 35mm (9.21 x 7.20 x 1.37")
Weight 376g (13.26oz)
