FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE C OMMUNICATION M ANUAL FC9Y-B1730 2-11
2: D EVICE
D8124
Cartridge Slot 2 Information
Type ID/Statu s ― R
D8125 System Software Version ― R
D8126
Cartridge Slot 3 Information
Type ID/Statu s ― R
D8127 System Software Version ― R
D8128 to
D8169
— Reserved — ――
D8170 Analog Cartridge I/O AI2/AQ2 Every scan R
D8171 Analog Cartridge I/O AI3/AQ3 Every scan R
D8172 Analog Cartridge Status AI2/AQ2 Every scan R
D8173 Analog Cartridge Status AI3/AQ3 Every scan R
D8174 Analog Cartridge I/O AI4/AQ4 Every scan R
D8175 Analog Cartridge I/O AI5/AQ5 Every scan R
D8176 Analog Cartridge Status AI4/AQ4 Every scan R
D8177 Analog Cartridge Status AI5/AQ5 Every scan R
D8178 Analog Cartridge I/O AI6/AQ6 Every scan R
D8179 Analog Cartridge I/O AI7/AQ7 Every scan R
D8180 Analog Cartridge Status AI6/AQ6 Every scan R
D8181 Analog Cartridge Status AI7/AQ7 Every scan R
D8182 to
D8191
— Reserved — ――
D8192
High-speed
Counter
(Group 2/I1)
High Word
Current Value/Frequency Measurement (I1) Current
Value
Every scan R
D8193 Low Word Every scan R
D8194 High Word
Preset Value
― R/W
D8195 Low Word ― R/W
D8196 High Word
Preset Value
― R/W
D8197 Low Word ― R/W
D8198
High-speed
Counter
(Group 6/I7)
High Word
Current Value/Frequency Measurement (I7) Current
Value
Every scan R
D8199 Low Word Every scan R
D8200 High Word
Preset Value
― R/W
D8201 Low Word ― R/W
D8202 High Word
Preset Value
― R/W
D8203 Low Word ― R/W
D8204 to
D8209
— Reserved — ――
D8210
High-speed
Counter
(Group 1/I0)
High Word
Current Value/Frequency Measurement (I0) Current
Value
Every scan R
D8211 Low Word Every scan R
D8212 High Word
Preset Value
― R/W
D8213 Low Word ― R/W
D8214 Interrupt Input Jump Destination Label No. (I7) ― R/W
D8215 Interrupt Input Jump Destination Label No. (I0) ― R/W
D8216 High-speed
Counter
(Group 1/I0)
High Word
Preset Value
― R/W
D8217 Low Word ― R/W
D8218
High-speed
Counter
(Group 3/I3)
High Word
Current Value/Frequency Measurement (I3) Current
Value
Every scan R
D8219 Low Word Every scan R
D8220 High Word
Preset Value
― R/W
D8221 Low Word ― R/W
D8222
High-speed
Counter
(Group 4/I4)
High Word
Current Value/Frequency Measurement (I4) Current
Value
Every scan R
D8223 Low Word Every scan R
D8224 High Word
Preset Value
― R/W
D8225 Low Word ― R/W
D8226
High-speed
Counter
(Group 5/I6)
High Word
Current Value/Frequency Measurement (I6) Current
Value
Every scan R
D8227 Low Word Every scan R
D8228 High Word
Preset Value
― R/W
D8229 Low Word ― R/W
Device
Address
Description Update Timing R/W
