2: D EVICE
2-12 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE C OMMUNICATION M ANUAL FC9Y-B1730
D8230
D8231
— Reserved — ――
D8232 High-speed
Counter
(Group 5/I6)
High Word
Preset Value
― R/W
D8233 Low Word ― R/W
D8234 High-speed
Counter
(Group 3/I3)
High Word
Preset Value
― R/W
D8235 Low Word ― R/W
D8236 High-speed
Counter
(Group 4/I4)
High Word
Preset Value
― R/W
D8237 Low Word ― R/W
D8238 — Reserved — ――
D8239 Absolute Position Control Status Every scan R
D8240
Absolute Position
Counter 1
High Word
Absolute Position
Every scan R
D8241 Low Word Every scan R
D8242
Absolute Position
Counter 2
High Word
Absolute Position
Every scan R
D8243 Low Word Every scan R
D8244
Absolute Position
Counter 3
High Word
Absolute Position
Every scan R
D8245 Low Word Every scan R
D8246
Absolute Position
Counter 4
High Word
Absolute Position
Every scan R
D8247 Low Word Every scan R
D8248
D8249
— Reserved — ――
D8250 Read SD Memory Card Capacity Every scan R
D8251 Read SD Memory Card Free Capacity Every scan R
D8252
D8253
— Reserved — ――
D8254 SD Memory Card Download/Upload Execution Information
When processing has
completed
R
D8255 SD Memory Card Download/Upload Execution Status
When processing has
completed
R
D8256 to
D8359
— Reserved — ――
D8260 Recipe Block Number ― R/W
D8261 Recipe Execution Block Number
When recipe execution
has completed
R
D8262 Recipe Execution Channel No.
When recipe execution
has completed
R
D8263 Recipe Execution Operation
When recipe execution
has completed
R
D8264 Recipe Execution Status
When recipe execution
has completed
R
D8265 Recipe Execution Error Information
When recipe execution
has completed
R
D8266 to
D8277
— Reserved — ――
D8278
Communication Mode Information
(Client Connection)
Connection 1 to 4 ― R
D8279 Connection 5 to 8 ― R
D8280 to
D8283
— Reserved — ――
D8284
Communication Mode Information
(HMI Connection)
HMI Connection 1 to 4 ― R
D8285 HMI Connection 5 to 8 ― R
D8286 to
D8303
— Reserved — ――
Device
Address
Description Update Timing R/W
