9: A NALOG I/O M ODULES
(1) Signal Type
The signal type that can be set differs according to the analog I/O module model. Select the analog I/O module that
corresponds to the user application and set the signal type. The signal type is the type of analog input to measure. There are 24
signal types for the analog inputs, which are detailed as follows.
Yes: Supported,
―: Not supported
Signal Type
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
FC6A-L06A1
FC6A-L06A4
FC6A-L03CN1
FC6A-L03CN4
Unused
*1
Yes Yes Yes Yes Yes Yes Yes Yes
0 to 10 V Yes Yes Yes Yes ――Yes Yes
-10 to +10 V Yes Yes Yes Yes ――Yes Yes
0 to 20 mA Yes Yes Yes Yes ――Yes Yes
4 to 20 mA Yes Yes Yes Yes ――Yes Yes
Type K thermocouple ―――Yes Yes Yes ― Yes
Type J thermocouple ―――Yes Yes Yes ― Yes
Type R t hermocouple ―――Yes Yes Yes ― Yes
Type S t hermocouple ―――Yes Yes Yes ― Yes
Type B t hermocouple ―――Yes Yes Yes ― Yes
Type E thermocoupl e ―――Yes Yes Yes ― Yes
Type T ther mocoupl e ―――Yes Yes Yes ― Yes
Type N thermocouple ―――Yes Yes Yes ― Yes
Type C thermocoupl e ―――Yes Yes Yes ― Yes
Pt100 ―――Yes ―――Yes
Pt1000 ―――Yes ―――Yes
Ni100 ―――Yes ―――Yes
Ni1000 ―――Yes ―――Yes
NTC thermistor ―――――Yes ――
PTC thermistor ―――――Yes ――
PTC thermistor
(threshold)
*2
―――――Yes ――
Resistance measurement ―――――Yes ――
Expansion 0 to 20 mA ――Yes ―――――
Expansion 4 to 20 mA ――Yes ―――――
*1 Channels that are set to unused are not scanned.
The circuit is setup the same as when signal type: 0 to 10 V is selected.
0 is always stored in the analog data storage data registers for channels that are set to unused.
*2 For details on PTC thermistor (threshold), see "PTC Thermistor (Threshold)" on page 9-10.
