IDEC MICROSmart FC6A Series User Manual

9: A NALOG I/O M ODULES
9-6 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
(2) Data Type
The analog input value can be handled as the set data type. There are seven data types for the analog inputs.
Yes: Supported,
―: Not supported
(3) Minimum and maximum values
The minimum and maximum values are determined by the set signal type (1) and data type (2).
The value is stored in the data (7) according to the minimum and maximum values.
The minimum and maximum values that correspond to the signal type and data types are as follows.
Data Type
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
FC6A-L06A1
FC6A-L06A4
FC6A-L03CN1
FC6A-L03CN4
Binary data
*1
YesYesYesYesYesYesYesYes
Optional range
*1
YesYesYesYesYesYesYesYes
Celsius
*2
―――Yes Yes Yes ― Yes
Fahrenheit
*2
―――Yes Yes Yes ― Yes
Resistance
*3
―――――Yes ――
Binary data
(16 bits)
――Yes
*4
―――――
Optional range
(16 bits)
――Yes
*4
―――――
*1 For only the FC6A-J8A1 and FC6A-J8A4, binary data (12 bits) and optional range (12 bits) are displayed.
*2 Can only be set when the signal type is thermocouple, resistance thermometer or NTC thermistor.
*3 Resistance when using the FC6A-J8CU1/FC6A-J8CU4 and the signal type is set to PTC thermistor or Resistance measurement.
*4 Binary data (16 bits) and optional range (16 bits) can be used with the following versions.
FC6A-J8A1, FC6A-J8A4: Version 200 or later
WindLDR: Version 8.6.0 or later
If an FC6A-J8A1 or FC6A-J8A4 that does not correspond to the above version numbers is set to binary data (16 bits) or optional range (16
bits), an error will occur and the module will operate as binary data (12 bits).
Signal Type
Data Type
Binary Data
(12 Bits)
*1
Optional
Range
(12 Bits)
*1*2
Celsius Fahrenheit Resistance
Binary Data
(16 Bits)
Optional
Range
(16 Bits)
0 to 10 V
0 to 65,535 -32,768 to 32,767 ―――0 to 65,535 -32,768 to 32,767
-10 to +10 V
-32,768 to 32,767 -32,768 to 32,767 ―――-32,768 to 32,767 -32,768 to 32,767
0 to 20 mA
0 to 65,535 -32,768 to 32,767 ―――0 to 65,535 -32,768 to 32,767
4 to 20 mA
0 to 65,535 -32,768 to 32,767 ―――0 to 65,535 -32,768 to 32,767
Type K thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 13,000 -3,280 to 23,720 ―― ―
Type J thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 10,000 -3,280 to 18,320 ―― ―
Type R t hermocouple
0 to 65,535 -32,768 to 32,767 0 to 17,600 320 to 32,000 ―― ―
Type S t hermocouple
0 to 65,535 -32,768 to 32,767 0 to 17,600 320 to 32,000 ―― ―
Type B t hermocouple
0 to 65,535 -32,768 to 32,767 0 to 18,200 320 to 33,080 ―― ―
Type E thermocoupl e
0 to 65,535 -32,768 to 32,767 -2,000 to 8,000 -3,280 to 14,720 ―― ―
Type T ther mocoupl e
0 to 65,535 -32,768 to 32,767 -2,000 to 4,000 -3,280 to 7,520 ―― ―
Type N thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 13,000 -3,280 to 23,720 ―― ―
Type C thermocoupl e
0 to 65,535 -32,768 to 32,767 0 to 23,150 320 to 41,990 ―― ―
Pt100
0 to 65,535 -32,768 to 32,767 -2,000 to 8,500 -3,280 to 15,620 ―― ―
Pt1000
0 to 65,535 -32,768 to 32,767 -2,000 to 6,000 -3,280 to 11,120 ―― ―
Ni100
0 to 65,535 -32,768 to 32,767 -600 to 1,800 -760 to 3,560 ―― ―
Ni1000
0 to 65,535 -32,768 to 32,767 -600 to 1,800 -760 to 3,560 ―― ―
NTC thermistor
0 to 65,535 -32,768 to 32,767 -900 to 1,500 -1,300 to 3,020 ―― ―
PTC thermistor
0 to 65,535 -32,768 to 32,767 ――100 to 10,000 ――
PTC thermistor (threshold)
*3
100 to 10,000 100 to 10,000 ―――― ―
Resistance measurement
0 to 65,535 -32,768 to 32,767 ――100 to 32,000 ――
Expansion 0 to 20 mA
0 to 4,095 -32,768 to 32,767 ―――0 to 65,535 -32,768 to 32,767
Expansion 4 to 20 mA
0 to 4,095 -32,768 to 32,767 ―――0 to 65,535 -32,768 to 32,767
*1 For only the FC6A-J8A1 and FC6A-J8A4, binary data (12 bits) and optional range (12 bits).
*2 The minimum and maximum values can be set only when the data type is set to optional range. Set the minimum and maximum values
between -32,768 and 32,767. However, when the signal type is set to PTC thermistor (threshold), set the minimum and maximum values
between 100 and 10,000. For the arbitrary setting, see
*4
in Chapter 2 "Product Specifications" on page 2-90.
*3 For details on PTC thermistor (threshold), see "PTC Thermistor (Threshold)" on page 9-10.
