FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-21
2: P
RODUCT
S
PECIFICATIONS
DC Input Specifications
■ AC Power Type, 24V DC Power Type
Type No.
FC6A-C16R1AE
FC6A-C16R4AE
FC6A-C16R1CE
FC6A-C16R4CE
FC6A-C16K1CE
FC6A-C16K4CE
FC6A-C16P1CE
FC6A-C16P4CE
FC6A-C24R1AE
FC6A-C24R4AE
FC6A-C24R1CE
FC6A-C24R4CE
FC6A-C24K1CE
FC6A-C24K4CE
FC6A-C24P1CE
FC6A-C24P4CE
FC6A-C40R1AE
FC6A-C40R4AE
FC6A-C40R1CE
FC6A-C40R4CE
FC6A-C40K1CE
FC6A-C40K4CE
FC6A-C40P1CE
FC6A-C40P4CE
FC6A-C40R1AEJ
FC6A-C40R4AEJ
FC6A-C40R1CEJ
FC6A-C40R4CEJ
FC6A-C40K1CEJ
FC6A-C40K4CEJ
FC6A-C40P1CEJ
FC6A-C40P4CEJ
Rated Input Voltage 24V DC shared sink/source
Input Voltage Range 0.0 to 28.8V DC
Rated Input Current
I0, I1, I6, I7 5 mA/point (at 24V DC)
I2 to I5, I10 to I27 7 mA/point (at 24V DC)
Terminal Arrangement See "AC Power Type" on page 2-34, "24V DC Power Type" on page 2-37
Input Impedance
I0, I1, I6, I7 4.9 kΩ
I2 to I5, I10 to I27 3.4 kΩ
Input Delay
Time
Turn ON
Time
I0, I1, I6, I7 5 μs + software filter setting
I2 to I5 35 μs + software filter setting
I10 to I27 35 μs + software filter setting
Turn OFF
Time
I0, I1, I6, I7 5 μs + software filter setting
I2 to I5 35 μs + software filter setting
I10 to I27 100 μs + software filter setting
Input Points
9 points in 1 common
line
14 points in 1 common
line
24 points in 1 common
line
Isolation
Between Input
Terminals
Not isolated
Internal Circuit Photocoupler isolated
Input Type Type 1 (IEC61131-2)
External Load for I/O Interconnection Not needed
Signal Determination Method Static
Effect of Improper Input Connection
Even if wiring for sink or source connection is incorrect, no damages are
caused.
However, if high voltage is applied that exceeds the input voltage range, there
is a risk of permanent damage.
Cable Length 3 m
I/O Terminal
Connector
Typ
e See "AC Power Type" on page 2-34, "24V DC Power Type" on page 2-37
Insertion/Removal Durability 100 times minimum
