MorphoWave Compact - 2018_2000035853-v81
terminal configuration through a USB mass storage key
connection with an external Wi-Fi
™
USB dongle using an adapter cable
Not evaluated by UL
LED1/LED2 to activate the access granted relay
12 to 24 V DC power supply (2.5A min @12V, 1.25A min @24V)
Or by Power Over Ethernet Plus through RJ-45 connector
Note for UL 294 Compliance power supply shall be UL 294 and UL
294B with power limited output
Anti-tamper-pulling switches
Tamper-pulling detection: one switch closed when product wall
mounted, open when pulled out
W x H x D: 152 mm x 250 mm x 220 mm
(6.98” x 9.84” x 8.66”)
Weight : ~ 2 kg
Operating temperature: -10 °C to + 55 °C (14°F to 131°F)
Operating humidity 10 % < RH < 80 % (non condensing)
Storage temperature -25 °C to + 70 °C (-13°F to 158°F)
Storage humidity 5% < RH < 95 %
IP65 rated
For UL 294 compliance, the products are rated for indoor use. IP65
was not verified by UL
The terminal should be installed in controlled lighting conditions
Avoid direct exposure to sunlight or to UV lights
CE, IEC 60950-1, FCC Part 15, RSS210 - Issue 8 : 2010, RSS-102 -
Issue 5 : 2015, RSS-Gen – Issue : 2014, RoHS, REACh, WEEE
