3.3.6 > Close the device on the base plate
Detach the device from the plate: first lift the device upwards, then pull it towards you, and hold it.
Figure 17: Product closure
Do not try to turn the product directly while it is attached on the base plate, as this would
definitely damage the plate and the device!
Then rotate the device 90° to align it in the final position in front of the plate. Push the device towards the
wall, then downwards until the device is locked on the plate.
Figure 18: Product fixation on wall frame
