iDirect Evolution X7 - 2.3 RF Specifications

Installation, Support, and Maintenance Guide 5
Evolution X7 Satellite Router
RF Specifications
2.3 RF Specifications
The Evolution X7 Satellite Router RF specifications are listed in Table 2-3.
Protection Over-Voltage Protection for LNB and BUC DC
Over-Current Limiting for LNB and BUC DC
Options 1 & 2: Primary AC fuse within PS module (250 VAC, T6.3 A)
Option 3: Primary DC fuse within PS module (250 V, 16 A)
AC Input Connector IEC-60320-C14, 3-cond, Male
AC Power Cord Supplied, per country of use
DC Input Connector Self-capturing terminal block, 14-16 AWG
Efficiency 87% Min
Table 2-2. Power Specifications (continued)
Category Description
Table 2-3. RF Specifications
Category Description
IF Interface, Impedance Type “F”, Zo = 75 ohms
Frequency Range
Transmit
Receive
950 - 1950 MHz
950 - 2150 MHz
Tuning Step Size
Transmit
Receive
10 Hz
55 KHz
RF Power
Transmit
Receive, Minimum
Receive, Maximum
Frequency Phase Noise
1 KHz -75
10 KHz -85
100 KHz -95
1 MHz -105
-35 to +5 dBm, 0.5 dB step
-130 + 10Log(Sym rate) dBm (Single carrier)
-5 dBm (Wideband Composite)
Tx SSB Phase Noise
LNB Support Fsym > 10 Msps: DRO LNB
Fsym
< 10 Msps: PLL LNB (internal reference)
Fsym
> 1 Msps: Universal LNB w/22 KHz tone
Receiver Noise Figure 15 dB
