Table 3-3. X7 Router Rear Panel Connector and LED Descriptions
Installation, Support, and Maintenance Guide 11
Evolution X7 Satellite Router
X7 Router Rear Panel Description
Callout Label Interface Definition and Connector Type
1 Grounding stud, #6-32tpi
2 no label Power Supply Module LED
OFF - No valid output
Green - Valid DC output
3 no label Power supply extraction handle
4 no label Terminal Block Header
Option 1 & 2: AC input connector IEC-320-C13
Option 3: DC input terminals - Negative, Positive, and
Ground; 14-16 AWG
5 LAN 1-8 Ethernet Communications Ports, RJ-45
6 BUC I/O BUC Communications Port, RJ-45
7 Console Console Communications Port, RS-232 Serial, RJ-45
8 +24, +48 BUC voltage selector switch
9 BUC PWR BUC Power LED: if off, no power to BUC
Green - No fault
Red - Over-current protection has tripped
10 TX OUT Transmitter Output (F)
11 none Internal Reset Switch
12, 14 LNB1, LNB2
PWR
LNB Power LEDs: if off, no power to LNB
Green - No fault
Red - Over-current protection has tripped
13, 15 (future) RX1 IN, RX2 IN Receiver Inputs (F), RX 2 IN is reserved for future use
