DM-F Series Monitor
Page 105
C.5.4
DDC Port Failure
The DDC port fail error message shown
below appears.
Figure C-18: DDC Port Failure
Solutions:
Check VGA
or HDMI ca
ble
Check an IEI monitor is being used
Make sure the version is versi
on 2.3 for the
AFOLUX/MDM serie
s and version
1.5 for the DM/ISDM/TDM/SRM/LCD-KIT
series that have the SmartOSD
functions
Check if the OSD control st
atus is
busy
.
A
busy signal may cause the signal
message for a short time.
