DM-F Series Monitor
Page 51
Figure 4-2 shows the 7-key membrane OSD keypad of the 12”–24” LCD monitors.
Figure 4-2: OSD Keypad for 12”–24” Monitors
The function of each button is described in the following table.
LCD on/off Press this button to turn on or turn off the LCD screen.
Auto Press this button to automatically adjust the screen.
Menu
Press this button to open the OSD window, exit the main menu or the current
menu.
Left
Press this button to increase the value. When inside a menu, press this button to
enter the submenu or confirm the selection of the item.
Right Press this button to decrease the value.
Up Press this button to scroll up from one selected item to another.
Down Press this button to scroll down from one selected item to another.
Table 4-2: OSD Control Buttons for 12”–24” Monitors
