DM-F Series Monitor
Page 61
NOTE:
The default touchscreen interface for the DM-F series monitor is USB
interface. The RS-232 interface is only reserved for the models with
resistive type touchscreen.
RS-232 Interface: If the touchscreen interface connection is an RS-232
connection, connect the RS-232 connector on the single board computer to
the DB-9 connector of the DM-F series monitor.
USB Interface: If the touchscreen interface connection is a USB connection,
connect the USB connector on the single board computer to the external USB
port connector of the DM-F series monitor.
5.3 Touch Panel Driver Installation
WARNING:
Before the touchscreen driver is installed, make sure the system is
connected to the monitor with a USB cable or an RS-232 null cable.
Also, make sure the VGA connector on the system is connected to the
VGA connector on the bottom of the monitor.
To install the touch panel driver for the DM-F series, please follow the instructions below:
Step 1: Connect the DM-F series monitor to the single board computer. See above.
Step 2: Install the driver CD. Install the driver CD into the system to which the DM-F
series monitor is connected.
Step 3: Select the Touch Screen option in the menu of driver CD. The directory in
Figure 5-1 a
ppears.
