IEI Technology DM-F12A/R-R10 User Manual

DM-F Series Monitor
Page 75
Power input connector 3-pin wafer, p=3.96 mm PWR2
Power input connector (+12 V) 2-pin wafer, p=2.00 mm CN15
Power output connector 2-pin wafer, p=2.00 mm CN16
RS-232 connector for touchscreen 6-pin wafer, p=1.25 mm RS232_1
SPI flash connector 6-pin wafer, p=1.25 mm JSPI1
USB connector for touchscreen 4-pin wafer, p=1.25 mm USB_TOUCH1
Touchscreen connector 9-pin wafer, p=1.25 mm J1
VGA connector 10-pin box header, p=2.00 mm VGA2
Jumper Type Label
Backlight voltage select jumper 6-pin header, p=2.54 mm JP5
LVDS panel voltage select jumper 6-pin header, p=2.54 mm JP2
Power input setting jumper 6-pin header, p=2.54 mm JP4
Touchscreen type select jumper 2-pin header, p=2.00 mm JP1
Table 6-11: AV-60381 Peripheral Interface Connectors
6.3.2 Backlight Inverter Connector (INVERTER1)
PIN NO. DESCRIPTION
1 BKL_POWER1
2 BKL_POWER1
3 ENABKL
4 BRIGHTNESS
5 GND
6 GND
Table 6-12: Backlight Inverter Connector (INVERTER1) Pinouts
