DM-F Series Monitor

Page 72

6.2.4 OSD Keypad Connector (CN14)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 +5V_OSD 2 +12V

3 OSD1 4 OSD2

5 OSD3 6 OSD4

7 OSD5 8 OSD6

9 OSD7 10 MLED8

11 GND 12 +3.3V_DVDD

Table 6-4: OSD Keypad Connector (CN14) Pinouts

6.2.5 Power Input Connector (CN9)

PIN NO. DESCRIPTION

1 GND

2 GND

3 VCC

4 VCC

Table 6-5: Power Input Connector (CN9) Pinouts

6.2.6 RS-232 Connector for Touchscreen (RS232_1)

PIN NO. DESCRIPTION

1 NDSR

2 NRX

3 NRTS

4 NTX

5 NDTR

6 GND

Table 6-6: RS-232 Connector for Touchscreen (RS232_1) Pinouts
