DM-F Series Monitor
Page 44
3.3.4 Wall Mounting
CAUTION:
Due to safety concerns, it is highly recommended to use the VESA
mounting kits provided by IEI for wall, stand and arm mounting. If the
VESA mounting kit is purchased separately, please make sure the
mounting kit is UL-listed.
Each model of the DM-F series LCD monitor has four holes located on the rear panel for
mounting the monitor to a wall. To mount the DM-F series LCD monitor onto a wall, please
follow the steps below.
Step 1: Attach the wall mounting kit to the mounting surface with the included screws.
Make sure it is attached securely (
5Figure 3-37).
Figure 3-37: Attach Wall Mounting Kit to the Wall
Step 2: Screw the mounting screws to the mounting holes on the rear of the DM-F series
(Figure 3-38).
Step 3: Hoo
k the DM-F series into the mounting holes on the wall mounting kit
(Figure 3-38).
