DM-F Series Monitor

Page 77

6.3.5 Power Input Connector (PWR2)

PIN NO. DESCRIPTION

1 +9 V ~ +36 V to external power module

2 GND

3 +12 V input

Table 6-15: Power Input Connector (PWR2) Pinouts

6.3.6 RS-232 Connector for Touchscreen (RS232_1)

PIN NO. DESCRIPTION

1 NDSR

2 NRX

3 NRTS

4 NTX

5 NDTR

6 GND

Table 6-16: RS-232 Connector for Touchscreen (RS232_1) Pinouts

6.3.7 USB Connector for Touchscreen (USB_TOUCH1)

PIN NO. DESCRIPTION

1 VCC_TOUCH

2 D2F-

3 D2F+

4 GND

Table 6-17: USB Connector for Touchscreen (USB_TOUCH1) Pinouts

6.3.8 Touchscreen Connector (J1)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 X+ 2 X-

3 Y+ 4 SENSE

5 X+ 6 X-
