ifm Programming Manual ecomatmobile BasicController (CR0403) Runtime System V03.02 2015-04-01
ifm function elements ifm function elements for the device CR0403
>
Parameters of the outputs
8081
OUTPUT BOOL TRUE: output is activated
FALSE: output is deactivated
CURRENT WORD only available for current controlable outputs:
current output current in [mA]
RESULT BYTE feedback of the function block
(possible messages → following table)
Possible results for RESULT:
Value
dec | hex
Description
0 00 FB is inactive
1 01 FB execution completed without error – data is valid
2 02 function block is active (action not yet completed)
3 03 function block is active – valid values not yet available
128 80 undervoltage on VBBx
129 81 overvoltage on VBBx
130 82 channel setting is invalid
132 84 mode setting is invalid
136 88 filter setting is invalid
141 8D a wire break was detected
(for binary output, plus switching (BH) with diagnosis)
142 8E a short circuit was detected
(for binary output plus switching (BH) with diagnosis)
145 91 current at the output is too high
(for binary output plus switching (BH) with diagnosis and protection)
