IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
18
7 Operating and display elements
Content
Overview .................................................................................................................................................18
LED indicators ........................................................................................................................................19
34063
>
7.1 Overview
34612
Status LEDs RDY, BF and SF
→ Status LEDs (→ S. 19)
Status LEDs LNK and ACT of the
PROFINET ports 1 (X21) and 2 (X22)
→ Ethernet interface (→ S. 19)
Status LED US of the power supply
(X31)
→ Voltage supply (→ S. 20)
Status LEDs IOL and DI of the IO-Link
ports Class A (X01...X08)
→ IO-Link ports (Class A) (→ S. 20)
