IFM IO-Link master-PROFINET AL1102 - Acyclic Data

IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
55
>
13.2.3 Acyclic data
Content
I&M datasets ...........................................................................................................................................55
Diagnostic and alarms ............................................................................................................................57
33868
>
I&M datasets
34555
The AL1102 supports the following I&M datasets (I&M = Identification & Maintenance):
>
I&M0 (Slot 0)
34545
Variable
Description
Access*
Size
Vendor ID
IO-Link ID of the manufacturer
r
2
OrderID
Order number of the device (numbers are separated by blanks)
r
20
Serial number
Serial number of the device (numbers separated by blanks)
r
16
Hardware revision
Hardware revision of the device
r
2
Software revision prefix
Prefix of the software revision of the device (V, R, P, U or T)
r
1
Software Revision
Software revision (numbers separated by blanks, e.g. x y z in "Vx.y.z")
r
3
Revision Counter
Revision counter; is incremented with each parameter change
r
2
Profile ID
ID of sub-module profile (Slot 0: 0x0000)
r
2
Profile Specific Type
additional value for profile ID; 0, if not used
r
2
IMVersion
I&M version (default value: 0x0101)
r
2
IMSupported
Suported I&M datasets (0x1110 for I&M1-3)
r
2
* ... r = only read
>
I&M1 (Slot 0)
34543
Variable
Description
Access*
Size
TagFunction of submodule
function of the device (ASCII, padded with spaces)
r/w
32
TagLocation of submodule
Location of the device in the plant (ASCII, padded with spaces)
r/w
22
* ... r/w = read and write
>
I&M2 (Slot 0)
34544
Variable
Description
Access*
Size
Installation_Date
Installation date of the device (ASCII, padded with spaces)
r/w
16
reserved
r/w
38
* ... r/w = read and write
