IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
>
9.1.3 IoT: Configure the interface to the LR SMARTOBSERVER
34048
To enable data transfer between the device and the LR SMARTOBSERVER monitoring software, the
LR SMARTOBSERVER monitoring software interface has to be configured.
► Select [IoT] menu.
> The menu page shows the current settings.
► Set the following parameters as required:
[IP address
LR SMARTOBSERVER]
IP address of the PC on which the
LR SMARTOBSERVER is installed.
Factory setting: 255.255.255.255
Port number that is used to send process data
to the LR SMARTOBSERVER
[Interval
LR SMARTOBSERVER]
Cycle time for the transfer of the process data to
the LR SMARTOBSERVER (value in
milliseconds)
Source identifier of the IO-Link master in the
structure of the LR SMARTOBSERVER
(String32)
After changing the parameter [Port LR SMARTOBSERVER] or [Application Tag], it may take
120 seconds before the device establishes a new TCP connection.
To prevent the delay:
► Reboot the device after the parameter change.
► Save changed values on the device.
>
9.1.4 Fieldbus: Set PROFINET interface
34589
For the access of the PROFINET interface the Ethernet ports X21/X22 need to be set:
► Select [Fieldbus] menu.
> The menu page shows the current settings.
► Set the following parameters as required:
IP address of the PROFINET interface
Subnet mask of the IP network
[Default gateway IP address]
IP adrress of the network gateway
MAC address of the PROFINETA interface
► Save changed values on the device.
