13.2.2 Cyclic data
Content
PROFINET modules ...............................................................................................................................53
PQI (Port Qualifier Information) ..............................................................................................................54
33814
>
PROFINET modules
34539
Module
Description
IO-Link 32I/32O + PQI
IO-Link activated
32 bytes input and output data and PQI
IO-Link 16I/16O + PQI
16 bytes input and output data and PQI
IO-Link 8I/8O + PQI
8 bytes input and output data and PQI
IO-Link 4I/4O + PQI
4 bytes input and output data and PQI
IO-Link 2I/ 2O + PQI
2 bytes input and output data and PQI
IO-Link 1I/1O + PQI
1 byte input and output data and PQI
IO-Link 1I/15O + PQI
1 byte input and 15 bytes output data and PQI
IO-Link 32I + PQI
32 bytes input data and PQI
IO-Link 16I + PQI
16 bytes input data and PQI
IO-Link 8I + PQI
8 bytes input data and PQI
IO-Link 4I + PQI
4 bytes input data and PQI
IO-Link 2I + PQI
2 bytes input data and PQI
IO-Link 1I + PQI
1 bytes input data and PQI
IO-Link 32O + PQI
32 bytes output data and PQI
IO-Link 16O + PQI
16 bytes output data and PQI
IO-Link 8O + PQI
8 bytes output data and PQI
IO-Link 4O + PQI
4 bytes output data and PQI
IO-Link 2O + PQI
2 bytes output data and PQI
IO-Link 1O + PQI
1 bytes output data and PQI
DI + PQI
IO-Link deactivated
Digital input and PQI
DO + PQI
Digital output and PQI
Disabled
deactivated
