9.2.7 Read I&M datasets
52484
I&M0 provide the user with device-specific basic information. This ensures reliable identification of the
device, the device's hardware and software components as well as the manufacturer.
The datasets I&M1 to 3 offer the programmer the possibility to store project-specific information on the
device.
The programmer can access the I&M0 datasets of the slots 0 and 1 in the PROFINET projection
software by means of the following functions:
Symbol / function
block
Description
Notes
GET_IM_DATA
 Function block for reading the I&M datasets of a device
 GET_IM_DATA only supports the reading of the I&M0
dataset
Input parameters:
 IM_TYPE = 0
RDREC
Function block for acyclic reading of datasets
Input parameters:
 I&M0: Index = 0xAFF0
 I&M1: Index = 0xAFF1
 I&M2: Index = 0xAFF2
 I&M3: Index = 0xAFF3
WRREC
 Function block for acyclic writing of datasets
 Observe access rights on datasets!
Input parameters:
 I&M1: Index = 0xAFF1
 I&M2: Index = 0xAFF2
 I&M3: Index = 0xAFF3
>
9.2.8 Detect diagnostics and alarms
52485
Available alarms and diagnostic messages: → Diagnostic and alarms (→ S. 57)
Symbol
Operational block
Description
I/O_FLT1
OB82
Diagnostic alarms
I/O_FLT2
OB83
Connect/disconnect alarms
RACK_FLT
OB86
Module rack failure
